Sell quartz Crystal HC49SMD 27.12Mhz Resonator

FOB Reference Price:Get Latest Price
US $0.03-0.455 / Pieces | 1000 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Anhui, China (Mainland)
Brand Name:
CSF
Model Number:
HC49SMD
Model::
HC49SMD 27.12Mhz Resonator
Nominal frequency ::
3.500-80.000MHZ
Mode of vibration ::
Fundament 3.5-30.0MHZ ; 3rd Voertone 30.0-80.0MHZ ; 20.0-40.0MHZ
Crt type ::
AT ; AT ; BT
Frequency tolerance ::
+/-20ppm , +/-30ppm , +/-50ppm
Load capacitance ::
8pf-33pf
Shunt capacitance ::
7.0pf max
Drive level ::
0.01-2.0mv max
Insulation resistance ::
500M Min/100 +/- 15V DC
Operating temperture ::
A)-10C--+60C B)-20C--+70C C)-30C--+80C D)-40C--+85C
Supply Ability
Supply Ability:
3000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Bulk pack
Port
Shanghai/Ningbo

Sell quartz Crystal HC49SMD 27.12Mhz Resonator

 HC49SMD 1.jpgHC49SMD 2.jpg49SSMD 2.JPG

Specification(Characteristics)

Frequency Range

3.200MHz - 110.000MHz

Mode of Oscillation

3.200MHz - 48.000MHz Fundamental

30.000MHz - 110.00MHz Third Overtone

Frequency Tolerance at 25C

+/-50ppm Max

(+/-5ppm,+/-10ppm,+/-30ppm Available)

Frequency Stability

Over Temperature

+/-50ppm Max

(+/-5ppm,+/-10ppm,+/-30ppm Available)

Operating Temperature Range

-10C - +60C standard, -40C - +85C extended

Storage Temperature Range

-40C - +85C

Aging

+/-5ppm / Year max

Load Capacitance

8pf - 32pf or series

Shunt Capacitance

7.0pf Max

Drive Level

0.01uW - 100uW

Reflow Conditions

260C for 10s Max, 2 reflows Max







Equivalent Series Resistance (ESR)

Frequency(MHz)

Mode

Ohm Max

3.200 - 4.000

Fundamental

120

4.001 - 8.000

Fundamental

80

8.001 - 30.000

Fundamental

40

30.001 - 50.000

Third overtone

100

50.001 - 90.000

Third overtone

80

90.001 - 110.000

Third overtone

60
